Rosin Resin Granule Granulator Making Machine
Description of resin granule granulator making machine
Rosin granulator making machine is using low melting point characteristic of the material (50 ℃ to 300 ℃) Molten material through the special distributing device . Then distributing it on moving steel belt.Under the belt, there are continuous sprayer and cooling device which can cool, solidify and pelletize material on belt as soon as possible. Then make the material condensation , solidification . granulation.
1. Granulator size can be choose between 4mm -12mm . Shapes can make granule, strip and flake.
2.Equipment adopts frequency control, can choose a suitable speed according to the nature of the material.
3.Product uniform particles, and beautiful, forming rate above 95%.
4.Widely used van, melting point of material between 50 ℃ to 300 ℃, all can granulation forming, toxic materials can be closed.
Technical parameter of resin granulator machine
Model | HS-WG60 | HS-WG120 |
Machine width | 600mm | 1200MM |
Machine length | 12000mm | 15000mm |
Size of mold | 1.8-2.2 mm | 1.8-2.2mm |
Size of products | 4-8mm(adjust) | 4-8mm(adjust) |
Product’s shape | hemispherical | hemispherical |
Capacity | 150-200kg/hour for paraffin | 400kg/h for paraffin |
200-300kg/hour for resin | 600-800kg/h for resin | |
200-300kg for RD | 600-800kg/h for RD | |
Motor | 5kw+1.5kw | 5.5+1.5kw |
Voltage | 380V,50HZ,3 phase | 380V,50HZ,3 phase |
Water pump | pressure: 0.3mpa water flow: 15-20 m3/h (equipped by user) | pressure: 0.4mpa water flow:30 m3/h (equipped by user) |
Pictures of resin granulation machine
Finished pellets
